Project #1653

733.5KW DC/680KW AC; Roof Mount; 51 Strings; 25-28 Modules per string It consists of 1384 Canadian Solar modules with 6 SolarEdge inverters. The project was designed with rooftop ballasted racking.

The new PV system is to be installed on the WP Carey, Rancho Cucamonga, California. The PV system is to be interconnected with the existing electrical distribution equipment via LV conductors.
